Digga Auger Drives (Excavator)

The Digga Auger Drives provide the power you need to get your excavator to task. Available for excavators between 1.8 right up to 30 tonne.

  • Compact high torque Digga manufactured gearbox
  • Highly efficient design with less moving parts
  • Fitted with Eaton/Digga geroler hydraulic motor
  • No case drain required
  • Full range of shafts available upon request
  • Extreme duty shaft locking system
  • HALO alignment system available for PD3-PD7 auger drives
  • Low maintenance with 5yr gear box and 3yr motor warrant

Order today!

Simply add this attachment to your cart to create an online order. Our team will then be in touch with confirmation of availability and to arrange for delivery. It’s that easy.

Digga Auger Drive Excavator

$2,049.30 - $42,595.30

Clear
Note: pricing includes GST
  • Date Format: DD slash MM slash YYYY
  • Date Format: DD slash MM slash YYYY
Play Video

ABOUT

Digga’s new generation premium drilling auger drive range is the ultimate in performance, quality and cost effectiveness. Digga auger drives come packed with really practical features like top mounted hose ports, cutting edge design, and a 2 piece shaft just to name a few.

It’s innovative design allows the gearbox to go down the hole to maximise drilling depth without extensions. This eliminates downtime and minimises maintenance so you can get the most return on investment. What’s more, the auger drives are fitted with Digga / Eaton bell motors specially designed for drilling and augering in most ground conditions.

Backed up with industry leading warranty and Australian factory backup. Digga auger drives are ideally suited to drilling and augering applications in most ground conditions.

PDX2 – PD5

Digga’s range of PDX2 – PD5 range of earth drills are suited for mini excavators between 2 – 5 tonnes and with a flow between 30 to 115 lpm.

PD5 – PD8

Digga’s range of PD5 – PD8 range of earth drills are suited for midi excavators between 5 – 8 tonnes and with a flow between 55 to 200 lpm.

PD15 – PD25

Digga’s range of PD15 – PD20 range of earth drills are suited for large excavators between 15 – 25 tonnes and with a flow between 120 to 230 lpm.

SD70

Digga’s SD70 is designed for large excavators that require a higher flow up to 380 lpm. It offers 2 speeds; high speed, low torque setting for the smaller auger jobs when you need that extra RPM, and low speed, high torque for when you really need to grind out that larger diameter hole. It’s like having 2 drive units in 1.

For other great products from Digga, click here.

SPECS

Brands

Application

,

1.8 - 2T excavators (PDX2):

Excavator Flow Range: 30 – 50 LPM
Max Torque: 2307 Nm
Max Pressure: Do not exceed 240 bar @ 60 lpm
Max Flow: Do not exceed 115 lpm @ 130 bar
Max Power: Do not exceed 25 Kw (34 hp)
Overall Length: 557 mm
Diameter: 187 mm
Weight (no frame/hitch): 45 kg
Std Output Shaft: 65 mm round
Max Auger Dia Clay/Shale: 450 mm
Max Auger Dia Earth: 600 mm

2 - 3.5T excavators (PD3):

Excavator Flow Range: 45 – 75 LPM
Max Torque: 3544 Nm
Max Pressure: Do not exceed 240 bar @ 60 lpm
Max Flow: Do not exceed 115 lpm @ 130 bar
Max Power: Do not exceed 25 Kw (34 hp)
Overall Length: 579 mm
Diameter: 240 mm
Weight (no frame/hitch): 57 kg
Std Output Shaft: 65 mm round
Max Auger Dia Clay/Shale: 600 mm
Max Auger Dia Earth: 750 mm

5T excavators (PD5):

Excavator Flow Range: 60 – 95 LPM
Max Torque: 5151 Nm
Max Pressure: Do not exceed 240 bar @ 60 lpm
Max Flow: Do not exceed 115 lpm @ 130 bar
Max Power: Do not exceed 25 Kw (34 hp)
Overall Length: 579 mm
Diameter: 240 mm
Weight (no frame/hitch): 58 kg
Std Output Shaft: 75 mm square
Max Auger Dia Clay/Shale: 750 mm
Max Auger Dia Earth: 1000 mm

8T excavators (PD8):

Excavator Flow Range: 80 – 200 LPM
Max Torque: 9690 Nm
Max Pressure: Do not exceed 240 bar @ 130 lpm
Max Flow: Do not exceed 230 lpm @ 130 bar
Max Power: Do not exceed 50 Kw (67 hp)
Overall Length: 950 mm
Diameter: 290 mm
Weight (no frame/hitch): 149 kg
Std Output Shaft: 75 mm square
Max Auger Dia Clay/Shale: 1000 mm
Max Auger Dia Earth: 1200 mm

15T excavators (PD15):

Excavator Flow Range: 130 – 230 LPM
Max Torque: 13897 Nm
Max Pressure: Do not exceed 240 bar @ 130 lpm
Max Flow: Do not exceed 210 lpm @ 145 bar
Max Power: Do not exceed 50 Kw (67 hp)
Overall Length: 1006 mm
Diameter: 290 mm
Weight (no frame/hitch): 176 kg
Std Output Shaft: 75 mm square
Max Auger Dia Clay/Shale: 1200 mm
Max Auger Dia Earth: 1600 mm

25T excavators (PD25):

Excavator Flow Range: 130 – 230 LPM
Max Torque: 26267 Nm
Max Pressure: Do not exceed 240 bar @ 130 lpm
Max Flow: Do not exceed 230 lpm @ 125 bar
Max Power: Do not exceed 50 Kw (67 hp)
Overall Length: 1152 mm
Diameter: 355 mm
Weight (no frame/hitch): 300 kg
Std Output Shaft: 100 mm square
Max Auger Dia Clay/Shale: 1500 mm
Max Auger Dia Earth: 1600 mm

30T excavators (SD70):

Max Torque: 68018 Nm
Max Pressure: Do not exceed 240 bar @ 380 lpm
Max Flow: Do not exceed 380 lpm @ 240 bar
Max Power: Do not exceed 150 Kw
Overall Length: 1493 mm
Diameter: 600 mm
Weight (no frame/hitch): 836 kg
Std Output Shaft: 100 mm square
Max Auger Dia Clay/Shale: 1500 mm
Max Auger Dia Earth: 1800 mm
