Buy:

RAMRADE Rock Breakers

The RAMRADE Rock Breaker has excellent hydraulic breakers with high frequency and impact energy. Built with high strength steel to withstand the toughest jobs and extreme conditions, they are made to last.

  • Size range suit up to 60 tonne excavators
  • Designed for extreme conditions
  • Noise reduction technology
  • Optional auto-greaser available
  • Fully shock absorbed

Order today!

Simply add this attachment to your cart to create an online order. Our team will then be in touch with confirmation of availability and to arrange for delivery. It’s that easy.

RAMRADE Rock Breakers Excavator attachment on white background

Note: pricing includes GST

ABOUT

RAMRADE Rock Breakers

Our Rock breakers are built with high strength steel to withstand the toughest jobs and extreme conditions. These hydraulic breakers incorporate excellent hydraulics with high frequency and impact energy. With great features such as noise reduction technology, large monobloc housing, and super shock absorber elements. The RAMRADE Rock Breakers is an industry-leading brand. They ensure a profitable investment that pays for itself over and over again.

RAMRADE Rock Breakers suit a wide range of excavators from 1.7 to 50 tonne. Also suits a wide range of popular excavator brands such as Kobelco, Hitachi, and Kubota.



About RAMRADE Attachments

RAMRADE Attachments is a world-class supplier of high-quality attachments to suit your excavator, skid steer, and other earthmoving equipment. They are manufactured to exceed rigorous global standards, and utilizing the most advanced technology. What’s more, these attachments are extensively field and factory tested to produce an outstanding range that consistently delivers. Browse the RAMRADE range

SPECS

Brands

100 Series

Pick-up Dimensions: 85-95-30 mm
Excavator Weight: 0.5 – 1.5 tonne
Weight: 100 kg
Required Oil Flow Range: 13 – 25 Lpm
Operating Pressure: 75 -100 Bar
Impact Range: 800 – 1,200 bpm
Chisel Diameter: 40 mm

200 Series

Pick-up Dimensions: 85-95-30 mm
Excavator Weight: 1.2 – 4 tonnes
Weight: 200 kg
Required Oil Flow Range: 20 – 30 Lpm
Operating Pressure: 80-110 Bar
Impact Range: 600 – 1000 Bpm
Chisel Diameter: 45 mm

300 Series

Pick-up Dimensions: 180-145-45
Excavator Weight: 3- 5 tonnes
Weight: 250kg
Required Oil Flow Range: 25 – 40 Lpm
Operating Pressure: 90 -120 Bar
Impact Range: 550 – 950 Bpm
Chisel Diameter: 53 mm

400 Series

Pick-up Dimensions: 245-170-45
Excavator Weight: 3.5 – 7 tonnes
Weight: 380 kg
Required Oil Flow Range: 30 – 45 Lpm
Operating Pressure: 95 – 130Bar
Impact Range: 500 – 900 Bpm
Chisel Diameter: 68 mm

430 Series

Pick-up Dimensions: 300-200-50 mm
Excavator Weight: 5 – 9 tonnes
Weight: 500 kg
Required Oil Flow Range: 40 – 80 Lpm
Operating Pressure: 100 – 130 Bar
Impact Range: 450 – 950 Bpm
Chisel Diameter: 75 mm

450 Series

Pick-up Dimensions: 375-270-65 mm
Carrier Weight: 7-12 tonnes
Required Oil Flow Range: 45-85 Lpm
Operating Pressure: 130 -150 Bar
Impact Range: 400 – 800 Bpm
Chisel Diameter: 85 mm

500 Series

Pick-up Dimensions: 375-270-65 mm
Carrier Weight: 10 – 14 tonnes
Required Oil Flow Range: 80 – 100 Lpm
Operating Pressure: 150 – 170 Bar
Impact Range: 450 – 700 Bpm
Chisel Diameter: 100 mm

600 Series

Pick-up Dimensions: 445-348-70/80 mm
Carrier Weight: 13 – 18 tonnes
Required Oil Flow Range: 90 – 120 Lpm
Operating Pressure: 150 – 170 Bar
Impact Range: 400 – 800 Bpm
Chisel Diameter: 120 mm
Price: POA

700 Series

Pick-up Dimensions: 460-350-80 mm
Carrier Weight: 18 – 26 tonnes
Required Oil Flow Range: 125 – 150 Lpm
Operating Pressure: 160 -180 Bar
Impact Range: 400 – 800 Bpm
Chisel Diameter: 135 mm

800 Series

Pick-up Dimensions: 460-350-80 mm
Carrier Weight: 18 – 28 tonnes
Required Oil Flow Range: 160-190 Lpm
Operating Pressure: 160 – 180 Bar
Impact Range: 350 – 750 Bpm
Chisel Diameter: 140 mm

1000 Series

Pick-up Dimensions: 460-350-90/ 585-420-100 mm
Carrier Weight: 28 – 35 tonnes
Required Oil Flow Range: 160 – 190 Lpm
Operating Pressure: 160 – 180 Bar
Impact Range: 360 – 700 Bpm
Chisel Diameter: 150 mm

1200 Series

Pick-up Dimensions: 475-420-90/585-420-100 mm
Carrier Weight: 30 – 40 tonnes
Required Oil Flow Range: 190 – 250 Lpm
Operating Pressure: 160 – 180 Bar
Impact Range: 210 – 450 Bpm
Chisel Diameter: 155 mm

1300 Series

Pick-up Dimensions: 475-420-90/585-420-100 mm
Carrier Weight: 33 – 48 tonnes
Required Oil Flow Range: 200 – 260 Lpm
Operating Pressure: 160 – 180 Bar
Impact Range: 210 – 450 Bpm
Chisel Diameter: 160 mm
Price: POA

1500 Series

Pick-up Dimensions: 375-270-65 mm
Carrier Weight: 40 – 60 tonnes
Required Oil Flow Range: 220 – 310 Lpm
Operating Pressure: 160 – 180 Bar
Impact Range: 210 – 450 Bpm
Chisel Diameter: 175 mm
