Kubota Excavator (0.8T)

The Kubota 0.8 tonne mini excavator is extremely versatile as it can go through a standard width doorway. It can be reduced to 700mm wide with the tracks retracted.

  • Protected auxiliary hoses
  • Two-speed travel
  • Straight wall trenching
  • Pedal operated boom swing
  • Adjustable width track frame
  • RAM trailer and Hino hire available

Simply add the equipment and attachments you would like to hire to your cart. Our team will then be in touch with pricing, confirmation of availability and to arrange for delivery. It’s that easy.

Kubota 0.8 Tonne Excavator


Note: pricing includes GST and a 1% environmental levy
Share on facebook
Share on email
Send to a friend



Dimensions & Weight

Overall Length: 2,750 mm
Overall Height: 2,230 mm
Overall Width: 800 mm
Operating Weight: 1,000 kg
SWL: 68 kg


Dig Reach: 2,870 mm
Dig Depth: 1,715 mm
Dig Radius: 3,075 mm

Approximate Fuel Consumption


Transport Method

Hino Hire, Tow Bar



Kubota 0.8 Tonne Excavator

Available from RAM Equipment, the Kubota 0.8 Tonne Excavator (KX008-3)  is the smallest in the RAM Fleet. It can go through a standard width doorway, whilst the tracks can be retracted to just 700m wide.

An ultra-compact excavator, the Kubota 0.8 Tonne Excavator allows a swing angle of up to 60 degrees, allowing you to dig a straight trench along any wall. In addition, all the hydraulic hoses are hidden with the boom and dipper arm. The cylinder is also mounted on top of the boom, increasing service life.

You’ll also find it more comfortable behind the operating levers of the KX008-3. That’s because Kubota have generously increased the space between the operating levers and the operator’s seat, and lengthened the floorboards.

What’s more, Kubota has increased the digging/dumping height, digging depths, and digging radius at ground level, improving productivity.

Other great features include two-speed travel, two-way lever, fast and easy maintenance, and comfortable operator’s seat.

The Kubota KX series are among the toughest excavators available on the market today. Delivering superior performance and luxury comfort, the Kubota KX series has an excavator to meet every operator’s needs.

For something a little larger why not consider our most popular 1.7 tonne excavator, or our 3 tonne excavator to take your needs to the next level.

RAM Equipment logo

The RAM Difference – we do more, so you can too!

RAM Equipment is a specialised equipment hire company. Our dedicated team is committed to exceeding your expectations. As your efficient equipment solutions specialists, we will work closely with you to plan and execute your project, ensuring you have the most efficient machines for the job. We also have a wide range of attachments to suit.
